GPS Cable-Ducting
ENA TS-approved cable ducting provides reliable, long-lasting protection for underground power cables. Engineered to meet strict industry standards, it delivers strong, durable performance in demanding installation environments.
GPS Cable-Ducting ENA TS-approved range is designed to give network operators and contractors complete confidence when protecting underground power cables. Manufactured to meet the stringent requirements of the Energy Networks Association, these PE cable ducts deliver reliable performance in both new installations and refurbishment projects.
Engineered from high-quality materials, the ducting provides exceptional resistance to impact and environmental stress. Smooth internal surfaces support efficient cable pulling, reducing installation time and minimising risk to installed cables.
The range is available in multiple diameters and pipe options (straight lengths and coils) to suit a wide variety of power distribution applications.
| Name : | GPS Cable-Ducting |
| Size : | 90mm - 400mm |
| Product type 1 : | Pipe |
| Material : | Polyethlene (PE) |
| Product Range : | GPS cable-ducting |
| Reference | Size | Gross weight | Length |
|---|---|---|---|
| 22527313 | 90mm | 25.56kg | 12m (stick) |
| 22527314 | 110mm | 38.04kg | 12m (stick) |
| 22527315 | 125mm | 49.32kg | 12m (stick) |
| 22527317 | 160mm | 80.64kg | 12m (stick) |
| 22527318 | 180mm | 102kg | 12m (stick) |
| 22527319 | 200mm | 125.76kg | 12m (stick) |
| 22527320 | 225mm | 159.24kg | 12m (stick) |
| 22527321 | 250mm | 195.84kg | 12m (stick) |
| 22527322 | 280mm | 245.52kg | 12m (stick) |
| 22527323 | 315mm | 310.8kg | 12m (stick) |
| 22527324 | 355mm | 394.68kg | 12m (stick) |
| 22527325 | 400mm | 501kg | 12m (stick) |
| 22559313 | 90mm | 106.5kg | 50m (coil) |
| 22559314 | 110mm | 158.5kg | 50m (coil) |
| 22559315 | 125mm | 205.5kg | 50m (coil) |
| 22559317 | 160mm | 336kg | 50m (coil) |
| 22559318 | 180mm | 425kg | 50m (coil) |
| 22560313 | 90mm | 213kg | 100m (coil) |
| 22560314 | 110mm | 317kg | 100m (coil) |
| 22560315 | v | 411kg | 100m (coil) |
| 22560317 | 160mm | 672kg | 100m (coil) |
| 22560318 | 180mm | 850kg | 100m (coil) |
